Page #16 background image
HGM6110/6120 AUTO START MODULE
HGM6110/6120 Auto Start Module ISSUE 2.0 2008-10-27 Page 16 of 24
Num
Parameter Range Default
Remark
31 Lost speed delay 0-20.0S 5.0
When speed is zero and remain for
the delay, send out shutdown alarm.
When the delay is zero, send out
warning alarm.
32 Charge fail volt (0-30)V 6.0
During generator is running, when
charge alternator WL/D+ voltage is
low than this point and remain for 5
seconds, generator will warning
alarm.
33 Battery over volt (12-40V) 33.0
When generator battery voltage is
over than the point and hold for 20
seconds, battery over voltage signal
is active. It’s a warning alarm.
34 Battery under volt (4-30V) 8.0
When generator battery voltage is
less than the point and hold for 20
seconds, battery under voltage
signal is active. It’s a warning alarm.
35 CT rate (5-6000)/5 500 Current transformer rate
36 Full load current (5-6000)A 500
Mains or generator set maximum
rated current.
37 Over current (50-130)% 120
When the load current is over than
the point, the over current delay is
initiated.
38 Over current delay (0-3600)S 1296
When load current is over than the
point and hold great than the timer,
send out over current signal. When
the delay is zero, over current is
disabled.
39 output1 set (0-9) 2 Energized to stop
40 Output2 set (0-9) 3 Idle control
41 Output3 set (0-9) 5 Close gens
42 Output4 set (0-9) 6 Close mains
43 Digit input1 set (1-16) 1 High Temperature input
44 Digit input1 delay 0-20.0S 2.0
45 Digit input2 set (1-16) 2 Low Oil Pressure input
46 Digit input2 delay 0-20.0S 2.0
47 Passwords set (0-9999) 1234
48 Crank disconnect (0-5) 2 Setting Item Is Given in Table 5.
49 Speed disconnect (0-3000)RPM 360
When engine speed is large than
this point, starter will disconnect.
50 Freq disconnect (10-30)Hz 14
When generator frequency is large
than this point, starter will
disconnect.
