HGM6110/6120 Auto Start Module ISSUE 2.0 2008-10-27 Page 17 of 24
Num Parameter Range Default Remark
51 OP disconnect (0-400)kPa 200
When engine oil pressure is large
than this point, starter will
disconnect.
52 Select AC system
0 3P4L
1 2P3L
2 1P2L
0 3P4L(3 phase 4 wire)
53 Select temp curve (0-8) 04 SGD(120 )℃
54 Select press curve (0-8) 04 SGD(10Bar)
55 Select level curve (0-5) 0 Not used
7.2 OUTPUT 1-4 TABLE (TABLE 2)
Num Content Description
0 Not used
1 Common alarm
The designated programmable output relay will
energize when any warning or shutdown fault
circuit has been activated.
2 Energised to stop
The designated programmable output relay will
energize when a stop signal has been activated.
The output will remain energized for pre-set timer
once the engine has come to a complete stop, then
de-energizes.
3 Idle control
The designated programmable output relay will
energize when the idle delay is not zero. The
output contact would typically be connected to the
“idle/run” input control of an electronic governor.
4 Preheat control
The designated programmable output relay will
energize during the preheat delay timer period and
also energize until the engine receive a crank
success signal. The preheat output is typically
used for an engine starting aid such as glow plugs.
5 Close Gens Switch generator breaker on.
6 Close mains Switch mains breaker on.(HGM6120)
7 Open ATS Switch breaker off. The output delay is 3 seconds.
8 Raise speed control
It’s active from entering warming to switching load
on.
9 Drop speed control
It’s active from idling in stopping to engine has
been stopped.
10 Reserve
7.3 DIGIT INPUT 1-2 TABLE (TABLE 3)
Num Content Description
0 Not used
