8. After all connections have been made, ensure that all wire connectors are firmly attached and that
there is no exposed copper.
9. Gently place the wires and switch into the wallbox (with LED at top of device) and screw into
place.
10. Before installing the faceplate, restore power to the circuit, and firmly press SwitchLinc Lite’s
rocker top until the switch snaps out of “System Off” position.
11. After testing SwitchLinc Lite for proper operation (as described on page 2), install the faceplate.
PROGRAMMING
Setting the Primary Address
Each SwitchLinc Lite requires a primary X-10 address to operate (ships with “A1” from the factory; up
to 256 addresses can be programmed with Housecodes A-Pand Unit Codes 1-16).
Please note that the following Housecode and Unit Code combinations should not be
assigned as primary addresses orscene addresses, because they are reserved forprogram-
ming: M16, N16, O16, and P16
1. Using the tip of a very small screwdriver, press and hold the small Set Button in the middle of
the righthand side of SwitchLinc Lite (see diagram on page 2) for approximately 5 seconds, until
the brightness LED flashes (and the light goes to 100% brightness). When you release the Set
Button, the nightlight LED will flash.
2. Within 30 seconds, transmit the desired primary address (housecode and unit code) from any
transmitter (e.g., TouchLinc). The light will blink and the nightlight LED will stop flashing.
Setting the Ramp Rate (Optional)
The “Ramp Rate” is the rate at which SwitchLinc Lite brings the brightness of the light up or down
when the switch is turned on locally or receives a powerline carrier (X-10) ON-command to its primary
address. The Ramp Rate is adjustable. The factory default is about 3 seconds. If you wish to change
the ramp rate, follow the instructions below.
4
Main Panel
120VAC
Line
Neutral
Red
Ground
Load
SwitchLinc 2-Way
(Model 1181 or 1182)
Neutral
SwitchLinc Multi-Way Wiring Diagram
Black Black
Grey
White
Grey
Light
Fixture
(s)
YellowYellow
Black
GroundGround
Optional Slave Switches
(Model 1135)
Note: When installing multiple SwitchLincs in a J-box, or many on the same circuit breaker, please see
specifications at the end of this manual for limitations and recommendations.
SwitchLinc Lite
(Model 2384)
5
1. Press and hold the rocker to adjust the Brightness LED level to correspond to the the desired
ramp rate (brighter = faster) according to the following table.
2. Tap the Set Button TWICE. The light will blink.
Setting the ON-Level (Optional)
The ON-Level is the default brightness level to which SwitchLinc Lite will adjust the light when the
switch is turned on locally or receives a powerline carrier (X-10) ON-command to its primary address.
The factory default is 100%. You can set the ON-Level to a fixed brightness level or to resume its
previous brightness level.
Setting a fixed brightness level:
1. Adjust the brightness of the light to the desired level by pressing and holding SwitchLinc’s
rocker.
2. Tap the Set Button ONCE. The light will blink.
Setting resume dim:
1. Turn the light off.
2. Tap the Set Button ONCE.
FACTORYRESET (TO DEFAULT SETTINGS)
1. Firmly press the bottom of the SwitchLinc Lite rocker until you hear a loud click. A“System
Off” sticker will be exposed on the top of the rocker. This completely removes the power from
the lighting circuit being controlled by the SwitchLinc Lite.
2. Press
and
hold the Set Button.
3. While continuing to hold the Set Button, press the top of the SwitchLinc rocker (as if to turn the
switch on).
4. Release the Set Button.
5.
WAIT
approximately 25 seconds until the Nightlight LED illuminates before using the switch
(SwitchLinc is rewriting all options to be as they were when they shipped from the factory).
Brightness LED Level Ramp Rate in Seconds
8 0.1
7 0.2
6 0.3
5 0.5
4 2.0
3 4.5
2 6.5
1 8.5
NO LED 9.0
