Location Part # Description
1 NC7115 NC71 Top Shell
2 NC7106 NC71 Lower Chassis
3 NC7122 NC71 Power Supply
3A NC7122RC NC71RC Power Supply
4 NC7123 NC71 Floating Cord
4A NC7123RC NC71RC Floating Cord
5 NC7107 NC71 Drive Motor
6 NC7113 NC71 Pump Motor
6A NC7113RC NC71RC Pump Motor
7 NC1004 NC71 Drive Brush (2pc Set)
8 NC7108 NC71 Drive Wheel Tube
9 NC7112 NC71 Non Drive Wheel Tube
10 NC7104 NC71 Brush Mount with Bearing and Drive Wheel (L & R) (1 Set/1Side)
11 NC7116 NC71 Tracks
12 NC7117 NC71 Track Wheels (Set of 6)
13 NC7105 NC71 Cable Strain Relief
14 NC7118 NC71 Track Wheel Covers (L & R)
15 NC7109 NC71 Handle
16 NC7110 NC71 Impeller Cover
17 NC7103 NC71 Brush Center Bracket
18 NC7119 NC71 Upper and Lower Gasket Seal
19 NC7111 NC71 Inner Quick Drain Flaps
20 NC7120 NC71 Filter Bag
21 NC7102 NC71 Bottom Lid
22 NC7101 NC71 Bottom Lid Door
23 NC7114 NC71 Top Return Flap
