Smart Power Systems
®
A. C. MODULAR GENERATOR SYSTEM
Page 10 of 56
Hydraulic
Pump
Operating
Speed
Standard Shaft
Optional Shaft
Mounting
Flange
Displacement
Continuous
Pressure (Max)
Peak Pressure
Standard
Rotation
Dry Weight
Piston w/pressure
compensated control
880-3000 RPM
continuous duty
SAE B 7/8”-13
Tooth Spline
SAE 1” parallel with key
SAE B-B 1” 15T Spline
SAE B-2 bolt mount
45cc per revolution
3500 psi (250 bar)
4600 psi (315 bar)
Engine right-hand
rotation (opposite
engine rotation
available upon request)
46 lbs
Piston w/pressure
compensated control
880-3000 RPM
continuous duty
SAE B 7/8”-13
Tooth Spline
SAE 1” parallel with key
SAE B-B 1” 15T Spline
SAE B-2 bolt mount
45cc per revolution
3500 psi (250 bar)
4600 psi (315 bar)
Engine right-hand
rotation (opposite
engine rotation
available upon request)
46 lbs
Piston w/pressure
compensated control
1100-3000 RPM
continuous duty
SAE B 7/8”-13
Tooth Spline
SAE 1” parallel with key
SAE B-B 1” 15T Spline
SAE B-2 bolt mount
45cc per revolution
3500 psi (250 bar)
4600 psi (315 bar)
Engine right-hand
rotation (opposite
engine rotation
available upon request)
46 lbs
Piston w/pressure
compensated control
850-2700 RPM
continuous duty
SAE B-B 1” 15
Tooth Spline
SAE 1¼” parallel with key
SAE B-2 bolt mount
60cc per revolution
3500 psi (250 bar)
4600 psi (315 bar)
Engine right-hand rotation
(opposite engine rotation
available upon request)
51 lbs
