Smart Power Systems
®
A. C. MODULAR GENERATOR SYSTEM
Page 11 of 56
Table 1
MODEL OF GENERATOR
HR-6.2, HR-8
HR-10, HR-110
Oil Cooler
Dimensions (Core)
9.75”D x 22.6” W x 2.25” H
9.75”D x 22.6” W x 2.25” H
Fan
Voltage
Amperage
12 Inch Pusher
12 Volts DC
22 Amps
12 Inch Pusher
12 Volts DC
22 Amps
Filter
10 Micron
10 Micron
Hydraulic Oil
(recommended)
(alternate)
Op. Temp. range
(deg. F.)
ISO Approved Hydraulic Fluid
Dexron III
-13° F to 195° F
ISO Approved Hydraulic Fluid
Dexron III
-13° F to 195° F
Hoses
Motor Inlet
All Others
3600 psi, SAE
1250 psi, SAE
3600 psi, SAE
1250 psi, SAE
Hose Fittings
JIC STD
JIC STD
Dry Weight
(without pump)
HR-6.2 255 lbs
HR-8 255 lbs
HR-10 280 lbs
HR-110 280 lbs
Dimension of Tray Asm.
32” L x 13.5” W x 17” H
(Including Reservoir)
32” L x 13.5” W x 17” H
(Including Reservoir)
Ambient Operating
Temperature Range
0F to 120F
0F to 120F
