5
DC Power Supply
Output Voltage DC 0V - 15V DC 0V - 15V
Load Stability < 0.01 0 ± 2mV < 0.01 ± 2mV
Temperature Coefficient < 300 ppm/°C < 300 ppm/°C
Ripple dB < 1 mvrms (virtual value) < 1 mvrms (virtual value)
Protection 1A - 3A (optional) 1A - 3A(optional)
The station is suitable for various kinds of soldering and disordering various kinds of electronic
components such as SOIC, CHIP, QFP, PLCC, BGA, SMD, etc.
The hot air rework station can be used for shrinking, paint drying, adhesive removal, thawing,
warming, and plastic welding.
The station can be used for mobile phone repair. It provides a power supply which is useful for cir-
cuit board testing, detecting a mobile radio signal’s strength, etc.
Hot Air Rework Station
1. In order for the hot air gun to work properly, the handle of the air gun must be removed from the
handle rack.
2. Connect the station to the power supply and press the on/off switch for the hot air rework station.
3. Press the “▲” button or the”▼” button to set the temperature of the hot air rework station. The dig-
ital LED display will show the current operating temperature of the work station.
4. When finished using the work station, put the handle of the hot air gun in the handle rack. The sta-
tion will automatically begin cooling the hot air gun.
Soldering Iron
1. Put the soldering iron handle on the iron frame.
2. Press the on/off switch of the station and press the “▲” button or the”▼” button to set the tempera-
ture of the soldering iron. The digital LED display will show the current operating temperature of
the soldering iron.
General Use
Operating Instructions
