Instructions for the Installer
For operation on 380-415V3N
∼
: use
an H05RR-F-type five-core cable (5 x
1.5 mm
2
).
For operation on 380-415V2N
∼
: use
an H05RR-F-type four-core cable (4 x
2.5 mm
2
).
For operation on 220-240V
∼
: use an
H05RR-F-type three-core cable (3 x 4
mm
2
).
The cable end to be connected to the
appliance must be provided with an
ground wire (yellow-green) at least 20
mm longer.
The manufacturer declines all responsibility for damage to persons
or things caused by non-observance of the above prescriptions or by
interference with any part of the appliance.
Overall dimensions: location of gas and electrical connection points (all
measures in mm).
A 110
B 770
C 150
D 170
7
