Instructions for the user
48
8.2 Removing the door
Raise levers on each hinge A to lock the hinges before attempting to
remove the door. Hold the door on both sides with both hands near hinges
B. Lift up the door forming an angle of about 45° and remove. To refit, slide
the hinges A into slots in oven frame. Locate the grooves (figure C) over
frame of oven in hinge cut out, lower the door and release the locking
levers (figure B).
8.3 Oven door seal
To permit thorough cleaning of the oven, the seal
may be removed. Before removing the seal, take off
the door as described above. Once the door has
been taken off, lift the tabs at the corners as shown
in the figure.
After cleaning, refit the seal with the longer side
horizontal and insert the tabs into the appropriate
holes starting from the top ones.
