Instructions for the installer
99
11.5 Positioning the skirt
WARNING: The skirt provided is an integral part of the product; it must be
fastened to the appliance prior to installation.
• Position the skirt above the top, taking care
to align holes A with holes B.
• Secure the skirt to the top by tightening
screws C.
11.6 Positioning and levelling the appliance
After making the electrical and/or gas connections, properly level
the appliance on the floor to ensure better stability. Screw or
unscrew the bottom part of the foot until the appliance is stable and
level on the floor.
11.7 Wall mounting instructions (some markets only)
1 Fasten a hook bolt (not supplied) into the wall at
a height (h) of 800 mm from the floor.
The installer must provide the hook bolt when installing the appliance.
2 Attach the snap hook to the chain.
3 Attach the end of the chain to the hook bolt
fastened in the wall.
4 Finally, connect the snap hook to the appropriate
hole on the back of the appliance.
