35
12.2 Cable replacement
• Unscrew the securing screws
from the cover terminal;
• Remove the tabs from the
cover terminals;
• Loosen the cable securing screws
from the lower part of the rear of the
oven ;
• Loosen the terminal cables;
• Replace the cable securing it to the
terminal as described on the label
on the rear of the appliance;
• When the cable has been replaced
repeat the steps described above in
reverse.
Make sure that the cables follow the best route in order to avoid any contact with
the oven.
WARNING: The tightening torque of the screws of the terminal supply wires
must be 1.5 - 2 Nm.
