User instructions
30
3. Description of the controls
3.1 Front panel
All the dishwasher controls are grouped on the front panel.
1 ON / OFF
AND
DELAYED START
SELECTOR
2
DELAYED START
INDICATOR DISC
3 HALF-LOAD
BUTTON
4 INFORM ATION DISPLAY
5 START/STOP
BUTTON
6
SELECTED PROGRAM
INDICATOR DISC
7 WASHING PROGRAM
SELECTOR SWITCH
8
RECESSED DOOR HANDLE
3.2 Information display
The dishwasher is equipped with a practical
DISPLAY
which provides information on the
programmed dishwasher functions.
HALF-LOAD INDICATOR LIGHT
DELAYED START INDICATOR LIGHT
CURRENT PROGRAM INFORMATION
(Remaining time indication and warnings for the most common problems)
RINSE AID WARNING LIGHT
REGENERATING SALT WARNING LIGHT
