35
24. Insert the font cover ⑭ of the hinge into the front of the inside. (two spots)
25. Insert the ventilation cover ⑮ into the rectangular floorcloth pan.
26. Attach the gasket ⒃ as shown
at the figure. Attach it to the
opposite side from the hinge
side. If the gasket is long, cut it
according to the length to use.
27. Insert the cap screw ⑬ as shown at the figure.
6. Procedure to install
5) Installation checkup and finishing work
