Smeg FB30AFNF - Components to Install

22
2. Components to install
ⓐ Door screw ⓑ Wood screw ⓒ Top bracket screw ⓓ Height adjusting nut
Spec Qty
D4×
L16
2
M5 6
D4×
L12
16
D4×6.5
4M54
-1
Spec Qty
Spec Qty
Spec Qty Spec Qty Spec Qty
ⓖ Spannerⓔ Bracket screw
(+) screw driver 2m tape rule
D4XL16 4
Spec Qty
Tools not
provided when
installing
⑬ Cap screw ⑭ Front cover of hinge ⑮ Ventilating cover ⒃ Gasket
Qty: 1EA
Qty: 1EA
Qty: 2EA
① Top cover of refrigerator
⑤ Hinge bracket
⑨
Depth adjusting bracket
ⓕ Hinge screw
Qty: 2EA
Qty: 1EA
Qty: 1EA
Qty: 2EA
② Hinge holder
⑥ Hinge bracket cover
⑩
Depth adjusting bracket cover
Qty: 2EA
Qty: 2EA
Qty: 1EA
Qty: 2EA
③ Depth adjusting bracket
(diameter = 5.5mm)
⑦ Paper jig
⑪Depth adjusting bracket cover
Qty: 1EA
Qty: 2EA
Qty: 1EA
Qty: 1EA
④ Depth adjusting bracket
(diameter = 8mm)
⑧ Top bracket of furniture door
⑫ Top bracket cover of furniture door
Qty: 2EA
