Installation
!Beforeplacingyournewapplianceintooperationpleaseread
theseoperatinginstructionscarefully.Theycontainimportant
informationforsafeuse,forinstallationandforcareofthe
appliance.
!Pleasekeeptheseoperatinginstructionsforfuturereference.
Passthemontopossiblenewownersoftheappliance.
Positioning and connection
Positioning
1. Placetheapplianceinawell-ventilatedhumidity-freeroom.
2. Donotobstructtherearfangrills.Thecompressorand
condensergiveoffheatandrequiregoodventilationto
operatecorrectlyandsaveenergy.
3. Ensuretheapplianceisawayfromanysourcesofheat
(directsunlight,electricstove,etc.).
Electrical connections
Aftertheappliancehasbeentransported,carefullyplaceit
verticallyandwaitatleast3hoursbeforeconnectingittothe
electricitymains.Beforeinsertingtheplugintotheelectrical
socketensurethefollowing:
• Theapplianceisearthedandtheplugiscompliantwiththelaw.
• Thesocketcanwithstandthemaximumpowerofthe
appliance,whichisindicatedonthedataplatelocatedon
thebottomleftsideofthefridge(e.g.150W).
• Thevoltagemustbeintherangebetweenthevalues
indicatedonthedataplatelocatedonthebottomleftside
(e.g.220-240V).
• Thesocketiscompatiblewiththeplugoftheappliance.If
thesocketisincompatiblewiththeplug,askanauthorised
techniciantoreplaceit(see Assistance).Donotuseextension
cordsormultiplesockets.
!Oncetheappliancehasbeeninstalled,thepowersupply
cableandtheelectricalsocketmustbeeasilyaccessible.
!Thecablemustnotbebentorcompressed.
!Thecablemustbecheckedregularlyandreplacedby
authorisedtechniciansonly(seeAssistance).
! The manufacturer declines any liability should these
safety measures not be observed.
Accessories
SHELVES*:withorwithoutgrill.
Duetothespecialguidestheshelvesareremovableand
theheightisadjustable(see diagram),allowingeasystorage
oflargecontainersandfood.Heightcanbeadjustedwithout
completeremovaloftheshelf.
TEMPERATURE*Indicatorlight:toidentifythecoldestareain
therefrigerator.
1. CheckthatOKappearsclearlyontheindicatorlight(see
diagram).
2. Iftheword“OK”doesnotappearitmeansthatthe
temperatureistoohigh:adjusttheREFRIGERATOR
OPERATIONknobtoahigher(colder)positionandwait
approximately10hoursuntilthetemperaturehasstabilised.
3. Checktheindicatorlightagain:ifnecessary,readjustit
followingtheinitialprocess.Iflargequantitiesoffoodhave
beenaddedoriftherefrigeratordoorhasbeenopened
frequently,itisnormalfortheindicatornottoshowOK.
Waitatleast10hoursbeforeadjustingtheREFRIGERATOR
OPERATIONknobtoahighersetting.
Start-up and use
Starting the appliance
! Before starting the appliance, follow the installation
instructions (see Installation).
!Beforeconnectingtheappliance,cleanthecompartments
andaccessorieswellwithlukewarmwaterandbicarbonate.
1. Inserttheplugintothesocketandensurethattheinternal
lightilluminates.
2. TurntheTEMPERATUREADJUSTMENTknobtoanaverage
value.Afterafewhoursyouwillbeabletoputfoodinthe
refrigerator.
Setting the temperature
Thetemperatureinsidetherefrigeratorcompartment
automaticallyadjustsitselfaccordingtothepositionofthe
thermostatknob.
1 =warmest
MAX=coldest
Werecommend,however,amediumposition.
Thecoolingsectionoftherefrigeratorislocatedinsidethe
backwalloftherefrigeratorcompartmentforincreasedspace
andimprovedaesthetics.Duringoperation,thebackwallwill
becoveredinfrostorwaterdropletsdependingonwhether
thecompressorisoperatingorpaused.Donotworry,the
refrigeratorisfunctioningnormally.
Chiller system
Theappliancecomeswithoneofthechillersystemsdescribed
below:takenoteofyoursysteminordertodeterminethemost
efficientfoodstoragemethod.
GB
*Variesbynumberand/orposition,availableonlyoncertain
models.
