Smeg LBS65 - Installation Removing Packaging Reinforcement; Opening the Transportation Locks; Connecting to the Drain; Adjusting the Feet

3 - EN
2 Installation
Removing packaging
reinforcement
Tiltthemachinetoremovethepackaging
reinforcement.Removethepackaging
reinforcementbypullingtheribbon.
Opening the transportation locks
ATransportationsafetyboltsmust
beremovedbeforeoperatingthe
washingmachine!Otherwise,the
machinewillbedamaged!
1. Loosenalltheboltswithaspanner
untiltheyrotatefreely(“C”)
2. Removetransportationsafetybolts
byturningthemgently.
3. Fitthecovers(suppliedinthebag
withtheOperationManual)intothe
holesontherearpanel.(“P”)
C Keepthetransportationsafetybolts
inasafeplacetoreusewhenthe
washingmachineneedstobemoved
againinthefuture.
C Nevermovetheappliancewithout
thetransportationsafetybolts
properlyfixedinplace!
Adjusting the feet
ADonotuseanytoolstoloosenthe
locknuts.Otherwise,theycanbe
damaged.
1. Manually(byhand)loosenthelock
nutsonthefeet.
2. Adjustthemuntilthemachinestands
levelandfirmly.
3. Important:Tightenalllocknutsup
again.
Connecting to the water supply.
Important:
• Thewatersupplypressurerequired
torunthemachinemustbe1-10bar
(0,1–1MPa).
• Connectthespecialhosessupplied
withthemachinetothewaterintake
valvesonthemachine.
• Ifyouaregoingtouseyourdouble
water-inletmachineasasingle(cold)
water-inletunit,youmustinstallthe
stopper*,suppliedwithyourmachine
tothehotwatervalve.
• Ifyouwanttousebothwaterinlets
oftheproduct,youcanconnectthe
hotwaterhoseafterremovingthe
stopperandgasketgroupfromthe
hotwatervalve.
*Appliesfortheproductssuppliedwitha
blindstoppergroup.
• Modelswithasinglewaterinlet
shouldnotbeconnectedtothehot
watertap.
Whenreturningtheappliancetoitsplace
aftermaintenanceorcleaning,careshould
betakennottofold,squeezeorblockthe
hoses.
Connecting to the drain
Thewaterdischargehosecanbeattached
totheedgeofawashbasinorbathtub.The
drainhoseshouldbefirmlyfittedintothe
drainastonotgetoutofitshousing.
Important:
• Theendofthedrainhosemustbe
directlyconnectedtothewastewater
drainortothewashbasin.
• Thehoseshouldbeattachedtoa
heightofatleast40cm,and100cm
atmost.
• Incasethehoseiselevatedafter
layingitonthefloorlevelorclose
totheground(lessthan40cm
abovetheground),waterdischarge
becomesmoredifficultandthe
laundrymaycomeoutwet.
• Thehoseshouldbepushedintothe
drainageformorethan15cm.Ifitis
