Burner and nozzle characteristics table (60 cm models)
1 Natural gas G20 - 20 mbar AUX SR R UR
Rated heating capacity (kW)
1.10 1.80 3.10 4.10
Nozzle diameter (1/100 mm)
73 93 128 142
Reduced flow rate (W)
400 500 800 1500
Primary air (mm)
3 1.5 1 1.5
2 Natural gas G20 - 25 mbar AUX SR R UR
Rated heating capacity (kW)
1.10 1.80 3.10 4.10
Nozzle diameter (1/100 mm)
70 87 120 142
Reduced flow rate (W)
400 500 800 1500
Primary air (mm)
3 1.5 1 2
3 Natural gas G25.1 – 25 mbar AUX SR R UR
Rated heating capacity (kW)
1.10 1.80 3.10 4.10
Nozzle diameter (1/100 mm)
82 100 135 150
Reduced flow rate (W)
400 500 800 1500
Primary air (mm)
2.5 1 1 1.5
4 Natural Gas G25 – 20 mbar AUX SR R UR
Rated heating capacity (kW)
1.10 1.80 3.10 4.1
Nozzle diameter (1/100 mm)
82 105 135 160
Reduced flow rate (W)
400 500 800 1500
Primary air (mm)
2.5 1 1.5 1.5
5 Natural Gas G27 – 20 mbar AUX SR R UR
Rated heating capacity (kW)
1.10 1.80 3.10 4.0
Nozzle diameter (1/100 mm)
82 105 145 160
Reduced flow rate (W)
400 500 800 1500
Primary air (mm)
2.5 1 1 1
6 Natural gas G2.350 – 13 mbar AUX SR R UR
Rated heating capacity (kW)
1.10 1.80 3.10 4.10
Nozzle diameter (1/100 mm)
100 126 175 200
Reduced flow rate (W)
400 500 800 1500
Primary air (mm)
2.5 1.5 1 1
