EN6
After unpacking the product, check for any damage during transport. In case of problems, contact the dealer or the After-Sales Service.
For built-in dimensions and installation instruction, see the pictures in page 2.
PREPARING THE CABINET FOR FITTING
RECOMMENDED POT BOTTOM WIDTHS
INSTALLATION
WARNING
- Install a separator panel under
the hob.
- The lower part of the product
must not be accessible after
installation.
- Do not fit the separator panel if
an undertop oven is installed.
• The distance between the underside of the appliance and the separator panel must respect the dimensions given in the figure.
• In order to ensure the correct operation of the product, do not obstruct the minimum required clearance between the hob and the top of the unit (min. 5 mm).
• If an undertop oven is installed, make sure the oven is equipped with a cooling system.
• Do not install the hob above a dishwasher or washing-machine, so that the electronic circuits do not come into contact with steam or moisture which could damage them.
• In the case of flush-mounted installation, call the After-Sales Service to request assembly of screws kit 4801 211 00112.
• To remove the hob, use a screwdriver (not provided) to prise off the perimeter clips on the underside of the appliance.
