Installation
37
EN
Burner and nozzle characteristics tables
1 Natural Gas G20 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
1.0 1.8 3.0 0.9 4.2
Nozzle diameter (1/100 mm)
72 97 115 70 97+97
Pre-chamber (printed on nozzle)
(X) (Z) (Y) (X) (Z)
Reduced capacity (W)
400 500 800 400 1600
2 Natural Gas G25 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
--- - -
Nozzle diameter (1/100 mm)
--- - -
Reduced capacity (W)
--- - -
3 Natural Gas G25 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
--- - -
Nozzle diameter (1/100 mm)
--- - -
Reduced capacity (W)
--- - -
4 Liquid Gas G30/31 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
1.0 1.8 3.0 0.9 4.2
Nozzle diameter (1/100 mm)
50 65 85 46 65+65
Reduced capacity (W)
400 500 800 400 1600
Rated capacity G30 (g/h)
76 131 218 65 305
Rated capacity G31 (g/h)
75 129 215 64 300
5 Liquid Gas G30/31 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
--- - -
Nozzle diameter (1/100 mm)
--- - -
Pre-chamber (printed on nozzle)
--- - -
Reduced capacity (W)
--- - -
Rated capacity G30 (g/h)
--- - -
Rated capacity G31 (g/h)
--- - -
6 City Gas G110 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
--- - -
Nozzle diameter (1/100 mm)
--- - -
Reduced capacity (W)
--- - -
7 City Gas G120 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
--- - -
Nozzle diameter (1/100 mm)
--- - -
Reduced capacity (W)
--- - -
