Installation
69
EN
Burner and nozzle characteristics tables
1 Natural Gas G20 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
1.0 1.8 2.9 1.1 3.9
Nozzle diameter (1/100 mm)
72 97 115 80 145
Pre-chamber (printed on nozzle)
(X) (Z) (Y) (H1) (H4)
Reduced capacity (W)
400 500 800 400 1600
2 Natural Gas G20 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
1.1 1.8 2.9 1.1 3.9
Nozzle diameter (1/100 mm)
72 94 108 75 135
Pre-chamber (printed on nozzle)
(X) (Z) (H8) (H1) (H4)
Reduced capacity (W)
400 500 800 400 1600
3 Natural Gas G25 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
1.0 1.8 2.9 1.0 4.0
Nozzle diameter (1/100 mm)
72 94 121 80 150
Pre-chamber (printed on nozzle)
(F1) (Y) (F2) (H1) (H4)
Reduced capacity (W)
400 500 800 400 1600
4 Natural Gas G25.1 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
1.1 1.8 3.0 1.0 4.0
Nozzle diameter (1/100 mm)
77 100 134 80 155
Pre-chamber (printed on nozzle)
(F1) (Y) (F3) (H1) (H4)
Reduced capacity (W)
400 500 800 400 1600
5 Natural Gas G25 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
1.0 1.8 2.9 1.1 3.9
Nozzle diameter (1/100 mm)
77 100 134 85 155
Pre-chamber (printed on nozzle)
(F1) (Y) (F3) (H1) (H4)
Reduced capacity (W)
400 500 800 400 1600
6 Natural Gas G27 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
1.0 1.8 2.9 1.0 3.9
Nozzle diameter (1/100 mm)
77 105 138 85 160
Pre-chamber (printed on nozzle)
(F1) (Y) (F3) (H1) (H4)
Reduced capacity (W)
400 500 800 400 1600
7 Natural Gas G2.350 AUX SR R UR2 int. UR2
Rated heating capacity (kW)
1.0 1.8 2.9 1.0 4.0
Nozzle diameter (1/100 mm)
94 120 165 100 200
Pre-chamber (printed on nozzle)
(Y) (Y) (F3) (0) (H4)
Reduced capacity (W)
400 500 800 400 1600
