Smith Performance Sprayers PERFORMANCE S100 - Page 11

KEY DESCRIPTION
14A PUMP HANDLE
14B PUMP LID
14C SPRING_670 X 048
14D PISTON POLE
14E VALVE SEAT
14F O-RING 30mm X 4mm, V
14G SHEET
14H LOCKNUT
14I AIR PUMP
14J FLAT WASHER, 1 GAL SS, V
14K CHECK VALVE
KIT #14 182534 PUMP
KEY DESCRIPTION
15A PUMP HANDLE
15B PRESS BUTTON
15C SPRING_670 X 048
15D FLAT WASHER
15E RETAINING RING
15F CLAMP, COVER
15G GAS LID
15H O-RING 105mm X 5.7mm
15I PISTON POLE
15J SPRING_1 X 048
15K VALVE SEAT
15L O-RING 30mm X 4mm, V
15M SHEET
15N NYLON-INSERT HEX LOCKNUT
15”O” O-RING 46mm X 3.5mm, V
15P AIR PUMP
15Q CHECK VALVE, PUMP, V
KIT #15 182522 PUMP
KEY# PART# DESCRIPTION
12-1 182490 1 GALLON STAINLESS STEEL TANK
12-1A 182678 PRESSURE RELIEF VALVE FOR 1
GALLON STAINLESS STEEL TANK
12-1B 182677 SHOULDER STRAP FOR 1 OR 3.5
GALLON STAINLESS STEEL TANK
13-1 182521 3.5 GALLON STAINLESS STEEL TANK
WITH PRESSURE RELIEF VALVE
13-1A 182679 PRESSURE RELIEF VALVE FOR 3.5
GALLON STAINLESS STEEL TANK
Page 11
KIT #14-1 182643 PUMP SEAL AND GASKET
REPAIR KIT FOR #182534
KIT #15-1 182644 PUMP SEAL AND GASKET
REPAIR KIT FOR #182522
