Smith Performance Sprayers S103EX - Page 9

Page 9
KITS, PARTS & ACCESSORIES CONTINUED
3A 182485 HANDLE, PUMP
3B 182899 HANDLE LOCKING COLLAR
3C 182704 SPRING (2)
3D 182484 4-TAB CLAMP
3E 182714 TANK COVER
3F 182712 FLAT WASHER
3G 182713 RETAINING RING
3H 183195 O-RING 105mm x 5.7mm, ENCAP.
3J 182715 PUMP ROD
3K 182706 VALVE SEAT
3L 182744 O-RING 30mm x 4mm, VE
3M 182707 PISTON PLATE
3N 182708 LOCKNUT
3P 182743 O-RING 46mm x 3.5mm,VE
3R 182710 PUMP BARREL
3S 182741 CHECK VALVE, PUMP, VE
KIT #3 182755 PUMP Viton Extreme
(Blue O-rings & Gasket)
KEY# PART# DESCRIPTION
5 182677 SHOULDER HARNESS
6 182567 NOZZLE, ADJUSTABLE, BRASS
7 176332 POLY CHECK VALVE
8
-1 182578 FLAT FAN TIP, BRASS, .2 GPM-65°
-2 176042P FLAT FAN TIP, BRASS, .2 GPM-80°
-3 176116 FLAT FAN TIP, BRASS, .4 GPM-80°
-4 176171 FLAT FAN TIP, BRASS, .5 GPM-80°
-5 182577 FLAT FAN TIP, BRASS, .5 GPM-95°
-6 182576 FLAT FAN TIP, BRASS, 1 GPN-110°
9
-1 182795 NOZZLE, #4 GREEN POLY, .07 GPM-80°
-2 182796 NOZZLE, #6 RED POLY, .10 GPM-80°
-3 182797 NOZZLE, #10 BLACK POLY, .10 GPM-80°
-4 182784 NOZZLE, #8 GRAY POLY, .13 GPM-80°
-5 182798 NOZZLE, #12 BROWN POLY, .20 GPM-80°
-6 182785 NOZZLE, #8 BRASS CONICAL
10 182750 ZL SHUT-OFF, VE
4A 183195 O-RING 105mm x 5.7mm, VE
4B 182741 CHECK VALVE, PUMP VE
4C 182744 O-RING 30mm x 4mm, VE
4D 182743 O-RING, 46mm x 3.5mm, VE
KIT #4 183120 PUMP GASKETS Viton Extreme
(Blue O-rings & Gasket)
KIT #11 183123 ZL, VITON EXTREME,
SHUT-OFF SERVICE KIT
11A 182467 FILTER, ZL SHUT-OFF
11B 182747 O-RING, 2.4mm x 11.2mm VE (2)
11C 182746 O-RING, 1.9mm x 4.2mm VE (2)
11D 182473 STEM, ZL SHUTOFF
11E 182748 SEAL, ZL SHUT-OFF, VE
11F 182472 BASE, VALVE SHUT-OFF
11G 182471 SPRING, ZL STEM
11H 182880 CAP, ZL SHUT-OFF, VE
KEY# PART# DESCRIPTION
182759 3.5 GALLON TANK, VITON EXTREME
(INCLUDES KEY #2)
2
183044 VITON EXTREME PRV ASSEMBLY
1
KEY# PART# DESCRIPTION
12
-1 182757 24” WAND ASSEMBLY, SS
(INCLUDES 12-2, 12-3)
-2 182479 NUT, SS, EXTENSION
-3 182749 SEAL, SS, EXTENSION, VE (2)
13 182571 HOSE ASSEMBLY
SERVICE KITS, PARTS & ACCESSORIES ARE AVAILABLE BY CONTACTING
The Fountainhead Group, Inc. - Customer Service Center
Monday - Friday 8 A.M. - 5 P.M., EST
Toll Free: 1-800-311-9903
or
e-mail: Info@TheFGI.com
or
Access online at: www.TheFountainheadGroup.com
www.smithperformancesprayers.com
