System Menu 8/9
Restore factory
default settings?
Fig. 2.19
WARNING: All settings
will be LOST!
Continue? ( :Yes)
Fig. 2.20
System Menu 9/9
Display event
history?
Fig. 2.21
Code:UO3, 6681S
Code:UO1, 6649S
Code:PO2, 6601S
Code:---, OS
Fig. 2.22
SYSTEM MENU 8: RESTORING FACTORY DEFAULT SETTINGS
Restore Factory Defaults restores the original factory
set voltages and waveforms in the 10 waveform storage
locations (Fig. 2.19). All the current settings will be
changed back to the Factory Default Settings. See
Appendix D on page 55 for a list of Factory Default
Settings.
This message will be displayed before the default settings
are restored and the user must press the Up arrow key
to confirm restoration of t those settings (Fig. 2.20).
Pressing any other key will abort this operation and return
to the status display.
SYSTEM MENU 9: EVENT HISTORY
The LR-24 records all errors and unusual events that
occur during use. This menu option allows a technician
to review the status codes stored during field use of the
LR-24 (Fig. 2.21).
This history file is an aid to troubleshooting if the LR-24
develops a problem. There is a table of error codes in
Appendix B of this manual (page 51). To exit from this
mode and return to the status screen, press the Enter key
(Fig. 2.22).
