FACTORY DEFAULT STORED WAVEFORMS:
1. DC, 100 volts, 400 watt power limit.
2. Standard pulse 30 Hz, 25% duty cycle, 100 volts, 400 watt power
limit.
3. Standard pulse 60 Hz, 25% duty cycle, 100 volts, 400 watt power
limit.
4. Standard pulse 15 Hz, 25% duty cycle, 100 volts, 400 watt power limit.
5. Standard pulse 90 Hz, 25% duty cycle, 100 volts, 400 watt power
limit.
6. Standard pulse 120 Hz, 25% duty cycle, 100 volts, 400 watt power
limit.
7. Burst of three pulses at 500Hz with 50% Duty cycle, 15Hz cycle fre-
quency, 100 volts, 400 watt power limit.
8. Burst of three pulses at 500Hz with 50% Duty cycle, 30Hz cycle
frequency, 100 volts, 400 watt power limit.
9. Dual output mode waveform:
Primary waveform - Burst of two pulses at 4Hz with 25% duty cycle,
1Hz cycle frequency, 100 volts, 400 watt power limit.
Secondary waveform - Standard Pulse 30 Hz, 25% duty cycle, 100
volts, 400 watt power limit.
10. Dual output mode waveform:
Primary waveform - Burst of three pulses at 4Hz with 25% duty cycle,
1Hz cycle frequency, 100 volts, 400 watt power limit.
Secondary waveform - Standard Pulse 30 Hz, 25% duty cycle, 100
volts, 400 watt power limit.
