Smith-Root LR-24 - Page 3

II
www.smith-root.com
LR-24
BACKPACK ELECTROFISHER
Items manufactured by companies other than Smith-Root carry the original manufacturer’s
warranty. Please contact product manufacturer for return instructions.
It is hereby noted that the hard copy O&M manual provided with this product is current as of the date of sale and no further.
The Manufacturer periodically updates O&M manuals as verbiage, settings, operational protocols, etc. are revised and provides
updated copies on the Manufacturer's web-site. End users should routinely check the Manufacturer's web-site for the most
up-to-date manual regarding their products (www.smith-root.com/support).
All Smith-Root, Inc. manufactured products are covered by a one-year warranty.
Credit & Refund Policy: Customers returning equipment - in new condition - will be given a refund within five days from the
date of the return. A return authorization must accompany returns. Valid equipment returns include, but are not limited to,
ordering incorrect equipment, funding deficits and defective equipment returned for reimbursement. All returns are subject
to a restocking fee and applicable shipping charges. The restocking fee is figured at 10% of the purchase price but not less
than $20.00. Customers receiving equipment in damaged condition will be referred to the shipping company for insurance
reimbursement.
07288 User's Manual LR-24, Rev.06 © 2013 Smith-Root, Inc. Vancouver, WA - USA
WARNING - Battery posts, terminals and related accessories contain lead
compounds, chemicals known to the state of California to cause cancer and
reproductive harm. Wash hands after handling.
CONTENTS (Cont.)
SECTION 6: BATTERY CARE, MAINTENANCE
UBC-24 Charger ..........................................39
How to Charge Batteries
..........................40
Available Batteries
....................................... 41
Battery Tips & Precautions
......................42
Battery Rating
..............................................43
Battery Life
....................................................43
Battery Storage
...........................................43
Effects of Temperature
.............................43
Maintenance Charger
& Diagnostic Equipment...........................44
SECTION 7:
ELECTROFISHING SAFETY
Safety ........................................................45-49
SECTION 8: APPENDICES
Appendix A:
Glossary of Terms
.......................................50
Appendix B:
LR-24 Event Codes
...................................... 51
Appendix C:
Anode Ring Maintenance
......................... 52
Appendix D:
Factory Default Stored Waveforms
..... 53
Appendix E:
Suspension System
....................................54
Appendix F:
Suspension Adjustments
.......................... 55
Appendix G:
Cleaning and Maintenance
...................... 56
Appendix H:
Model 12 and 15 Conversion Chart
........ 56
Appendix I:
Electrode Testing
........................................ 57
Appendix J:
Backpack Electrofishing Illustration
.... 58
Appendix K:
Carry Case Arrangement Illustration
... 58
