34
www.smith-root.com
LR-24
BACKPACK ELECTROFISHER
5. Press the Volts key and use the Arrow keys to scroll to the
desired voltage and then press the Enter key (Fig. 5.26).
6. Press the Power Limit key and use the Arrow keys to scroll
to the desired power limit and then press Enter (Fig. 5.27).
7. Repeatedly press the Up arrow key until the Secondary
Waveform parameters are displayed. Repeat steps 2
through 6 for the Secondary Waveform.
8. Begin electrofishing.
9. Duty cycle and frequency can have a huge impact on taxis.
In general, lower frequencies are safer for larger fish than
higher frequencies. If you are not getting any response
from fish, change the LR-24 settings according to adjust-
ments a, b, and c on page 27.
SECTION 5: SETUP AND OPERATION (CONT.)
Voltage
150V
Fig. 5.26
Voltage
150V
Fig. 5.27
To Next Page
