02/2008
If you have damaged or missing components please contact customer service.
www.smithsystem.com
1.
Form #179820
THE KEYHOLE-SHAPED SLOTS ARE FACE DOWN.
2. REMOVE THE DRAWER PED FROM THE CARTON. TURN THEM UPSIDE DOWN SO THAT
LAY THE TOP UPSIDE DOWN WITH THE CUT OF THE T-MOLD AT THE BACK. MAKE SURE
FORWARD (TOWARDS YOU).
800-328-1061
FACING UPWARDS.
THE LAMINATE IS FACE DOWN AND THE PRE-ATTACHED MOUNTING PLATES ARE
3. SECURE THE DRAWER PED ON THE MOUNTING PLATE. ALIGN SLOTS ON
DRAWER PED TO KNOBS ON MOUNTING PLATE. BE CAREFUL NOT TO FORCE
THE PARTS TOGETHER. THE KNOBS ON THE PLATE SHOULD COMFORTABLY
ALIGN WITH THE SLOTS. ONCE THE PED IS SEATED ON THE PLATE, SLIDE THE PED
SLIDE FORWARD
T-MOLD CUT
BACK
FRONT
PRE-ATTACHED
PLATE
BACK
FRONT
To Next Page
