A
ATTACH PANEL TO TOP
USING 2 SHEET METAL SCREWS
SCALE 1 : 4
DETAIL A
NOTCHES SHOULD BE
FACE DOWN
MACHINE SCREWS
SHEET METAL SCREW
B
DETAIL B
SCALE 1 : 4
USE THREE (3)
2.5" SCREWS
7. ATTACH LEG TO TOP.
www.smithsystem.com
ATTACH PANEL HERE
INTEGRITY OF THE ASSEMBLY.
TURN THE UNIT OVER (UPRIGHT).
NOTE: USE CAUTION WHEN REPOSITIONING THE UNIT AT ANY TIME. DRAGGING THE DESK
800-328-1061
SCREWS USING AN ELECTRIC DRILL AT THE LOWEST TOQUE SETTING. HEX KEYS
If you have damaged or missing components please contact customer service.
9. WITH THE HELP OF AT LEAST ONE OTHER PERSON, CAREFULLY LIFT THE DESK AND
6. ATTACH THE MODESTY PANEL TO THE LEGS. THEN ATTACH THE PANEL TO THE TOP.
Form #179820 02/2008
ARE PROVIDED TO ASSIST TIGHTENING THE CONNECTOR BOLTS.
ACROSS THE FLOOR OR ROCKING THE DESK ON 2 OF THE 4 LEGS WILL WEAKEN THE
8. THE UNIT IS NOW ASSEMBLED. YOU SHOULD NOT HAVE ANY REMAINING SCREWS
IN THE HARDWARE PACK. TIGHTEN THE MACHINE SCREWS AND THE SHEET METAL
