SERIES 19HE BOILER
INSTALLATION INSTRUCTIONS
19. START UP AND MAINTENANCE INSTRUCTIONS
A. For best performance of the boiler, the following
suggestions should be performed by a qualifi ed boiler room
technician, through a regular program of maintenance and
adjustment to obtain the following.
1. Oil burner combustion: 11 - 12.5% CO2, zero smoke, smooth
lightoff and operation.
Gas burner combustion: 8.5 - 10.5% CO2 with smooth lightoff
and operation. Carbon Monoxide (CO) values under 50 ppm
must be maintained in smoke head
2. Keep boiler fi reside surface clean. Flue gas temperature
reading above 450°F over boiler room temperature signals
the start of soot accumulation. Inspect at least twice each
year.
3. Steam boiler water condition should be observed. Unstable
water line, system steam hammer indicate dirty water. Blow-
down is recommended. However, the introduction of excess
raw water to a steam boiler can result in the deposit of scale
and ineffi cient operation of physical damage to the boiler.
4. Float operated and probe type low water cutoff devices
should be maintained according to the instructions of the
manufacturer.
5. Limit control function should be checked on a regular basis.
6. Flame safeguard controls should be checked regularly.
B. The products of combustion must be conducted to the
outdoors by means of a metal connector of at least the same
size as the boiler smokehood outlet and a chimney or stub-
stack. The boiler is constructed for pressurized operation and
the burners are selected for operation against a back pressure
between .05 and .10" wc at the boiler outlet. If the actual
conditions cause a back pressure in excess of 0.10 ins. w.c. at
the boiler outlet, consult the Smith Co. for verifi cation of burner
size. If the chimney has the ability to develop excess draft, a
barometric draft control should be installed in the chimney.
Check with the Smith representative for assistance.
18. CLEANING BOILER WATERWAYS
A. STEAM BOILERS
NOTE: The boiler should be cleaned before connecting
system piping and installing steam trim.
1. Plug unused openings all around the boiler leaving a valved
overfl ow pipe connected to the safety valve tapping. Also
provide a valved blow-down connection to one of the bottom
tappings.
2. The fuel burning equipment should be installed and made
ready to operate in accordance with the burner instructions.
3. Fill the boiler with water to the middle of the upper port,
adding a boiler cleaning compound, as recommended in
A.S.M.E. Section VI.
4. Fire the boiler for at least one hour at a low rate to circulated
the cleaning compound through the boiler.
5. Blow off surface of boiler water through skimmer connection
or through safety valve opening by feeding clean water into
the boiler through a bottom fi ll connection.
6. When the water coming off the surface runs clear, shut off
the burner, close the top valve and open the bottom blow-
down valve. If there is a slight steam pressure in the boiler,
it will assist the blow-down.
7. When the sections have cooled after blow-down, fl ush the
interior of the boiler from the top by introducing water from
a hose through the top port. When the water runs clear,
complete the system piping, install the steam trim and
controls. Fill the boiler with clean water. Heat the boiler
water to at least 180°F to release corrosive gases.
B. WATER BOILERS
NOTE: The system piping should be completed before
cleaning the boiler.
1. Add an approved boiler compound. Follow the compound
manufacturer's instructions for best results. Fill the system
and vent air wherever necessary.
2. Heat the water to at least 180°F and circulate through all
the piping system. After about one hour, drain the system
thoroughly. Wash the interior of the boiler with a hose
inserted through the top tapping. When blow-down water
runs clean, allow boiler to cool, then fi ll the system with
clean water.
3. Heat the water up to about 180°F and vent air as necessary
to purge the system. The boiler is now ready to operate.
Boiler No. Draft Loss
(in W.C.)
Overfi re
Pressure
(in W.C.)
19HE-3 0.18 0.28
19HE-4 0.18 0.28
19HE-5 0.20 0.30
19HE-6 0.23 0.33
19HE-7 0.26 0.36
19HE-8 0.29 0.39
19HE-9 0.32 0.42
19HE-10 0.35 0.45
19HE-11 0.38 0.48
19HE-12 0.41 0.51
To Next Page
