SERIES 19HE REPLACEMENT PARTS
19HE
Cleanout Cover Assembly includes:
Cleanout Plate, Insulation and Rope
9 Clean Out Cover Plate Assy** 70361
— Rope Seal (45") 76538
— Silicone Sealant 10.3oz 61924
10/11/12 C/O Cover Hardware Kit* (2 sections) 21-1501
Burner Mounting Plate Assembly includes:
Mounting Plate with Observation Glass and Cover
13 Burner Mounting Plate Assy 70465
6
1
/
8
" Opening
Burner Mounting Plate Assy 70466
7
3
/
4
" Opening
Burner Mounting Plate Assy 70491
9
1
/
8
" Opening
— Burner Mounting Plate H'ware 71316
14 Observation Glass Only 60326
15 Observation Glass Gasket 60317
16 Observation Glass Gasket 60318
17 Observation Glass Holder 60314
— Screws, Observation Glass 61757
18 Observation Cover Plate 3420
19 Rope Seal
1
/
4
" x 4.75 ft. 78105
20 Burner Insulating Block 60434
Burner Insulating Block 60430
(3-6 Sect. – Beckett)
— Burner Insulating Block H'ware 71268
21 Upper Port Gasket (Viton) 60339
1 per Section
22 Lower Port Gasket (Viton) 60340
1 per Section
23 Target Wall (3-6 Sect. only) 69761
24
5
/
8
" x 9" Draw Rod 60101
25
5
/
8
" Hex Nut 60877
26
5
/
8
" Washer 62099
– Flue Brush 60090
27
3
/
8
" Rope (10' 4" per sect.) 78100
– Spray Adhesive 70492
28 Rear Observation Port Cover 3679
(3-6 Section)
29 Rear Observation Port Assy 70614
(7-12 Section)
— Rear Observation Port H'ware 71301
Steam Trim and Controls
30 3
1
/
2
" Steam Gauge 60269
31 Gauge Glass
5
/
8
" x 9
7
/
8
" 61862
32 1" Steam Relief Valve 61982
(3-5 Sect. on 19 & 19A)
1
1
/
4
" Steam Relief Valve 61983
(6-10 Sect. on 19) (6-8 Sect. on 19A)
1
1
/
2
" Steam Relief Valve 61984
(11-12 Sect. on 19) (9-12 Sect. on 19A)
33 PA404A Operating Control 50493
34 L4079B Limit Control 50495
Water Trim and Controls
35 3
1
/
2
" Theraltimeter 60267
36
3
/
4
" Relief Valve 61997
(3-10 Sect. on 19) (3-8 Sect. on 19A)
1" Relief Valve 61998
(11-12 Sect. on 19) (9-11 Sect. on 19A)
1 1/4" Relief Valve (19A-12) 61999
37 L4006A Operating Control 50511
38 L4006E Limit Control 14-1001
