35
Parts
78-415 2-BANK VALVE PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1* 78-415-01 Body (complete with spacer and check valve) 1
2* 78-415-02 Spool HDM10 1
3* 78-415-03 O-Ring Seal 6
4* 78-415-04 Flanged Washer HDM10 3
5* 78-415-05 Spacer 3
6* 78-415-06 A Type Spool HDS11 3
7* 78-415-07 Positioner 2
8* 78-415-08 Plug 3
9* 78-415-09 Lever Group HDS11 3
10* 78-415-10 Metric Socket Screw M5 x .8 x 45 6
11* 78-415-11 Positioner 1
12* 78-415-12 Check Valve Assembly HDM12 1
13* 78-415-13
3
/
4
- 16 SAE 8 Screw Plug 3
14 18-168 Elbow 3/8 Straight Thread 2
15 18-202 Elbow 2
16 18-169 Adapter SAE 3/8 4
17 78-418 Bent Handle 2
18 Tapered Knob 3
* 78-415 2 – Bank Hydraulic Valve (includes all * items)
