78-201 REPLACEMENT BRUSH REEL PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 78-222 Mounted Bearing 2
2 HB-38-16-125 Bolt
3
/
8
- 16 x 1
1
/
4
8
HNFL-38-16 Flange Whiz Lock Nut
3
/
8
- 16 8
3 HG-14-28-180 Grease Fitting
1
/
4
-20 x 180° (comes with 78-222) 2
4 78-348 Spiral Brush Shaft 1
5 HKSQ-14-100 Machine Key
1
/
4
x
1
/
4
x 1 2
6 78-321 Spiral Brush 1
78-202 REPLACEMENT FINGER REEL PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HB-38-16-125 Bolt
3
/
8
- 16 x 1
1
/
4
8
HNFL-38-16 Flange Whiz Lock Nut
3
/
8
- 16 8
2 78-222 Mounted Bearing 2
3 HG-14-28-180 Grease Fitting
1
/
4
-20 x 180° (comes with 78-222) 2
4 HKSQ-14-100 Machine Key
1
/
4
x
1
/
4
x 1 1
5 78-303 Finger Reel Bar 1
6 8969-5.250 Sweeper Finger 81
7 78-297 Finger Clamp 10" 17
8 78-326 Finger Clamp 12" 1
9 78-287 Finger Clamp 13" 1
10 78-327 Finger Clamp 10.5" 1
11 HNFL-516-18 Flange Whiz Lock Nut
5
/
16
- 18 40
