10 Specifications
Specifications Specifications
Specifications
Rated Line Pull: 1000Lbs (4535kgs) single-line
Motor: 5.5hp/12V, Series Wound
Control: Remote Switch, 12’ (3.7m) lead
Gear Train: 3-Stage Planetary
Gear Ratio: 218:1
Clutch: Rotating Ring Gear
Brake: Automatic In-The-Drum
Drum Size: (Diameter x Length) 2.5” x 8.82” (63.5mm x 224mm)
Wire Rope: (Diameter x Length) 23/64” x 94’ (9.2mm x 28.5m)
Fairlead: 4-Way Roller
Remote Control: Included
Recommended Battery: 650CCA Minimum for Winching
Battery Leads: 25mm
2
, 72” (1.8m)
Finish: Black
Weight: 99.0lbs (42.5Kgs)
Mounting Bolt Pattern: 10.0” x 4.50”
Line speed and amp draw (first layer)
Lbs 2000 4000 6000 8000 10000
Line Pull
Kgs
NO LOAD
907 1814 2721 3628 4535
Fpm 29.53 14.44 12.14 10.17 8.86 7.38
Line Speed
Mpm 9 4.4 3.7 3.1 2.7 2.25
Motor Current Amps 70 170 240 310 380 425
Line pull and cable capacity
Layer of cable 1 2 3 4
Lbs 10000 8633 7716 7089
Rated line pull per layer
Kgs 4535 3915 3499 3215
Ft 16 42 72 94
Cable capacity per layer
Mpm 4.88 12.8 21.95 28.5
