Smittybilt XRC 8 User Manual

For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Page 14 of 17
XRC
XRC XRC
XRC 12
1212
12 WINCH PARTS LIST
WINCH PARTS LIST WINCH PARTS LIST
WINCH PARTS LIST
No. Parts No. Description Qty No. Part No. Description Qty
1 97212-01 Washer 2 26 97212-26 Gear Box Tube 1
2 97212-02 Sun Gear-Input 1 27 97212-27 Inner Gear 1
3 97212-03 Gear Carrie-Input 1 28 97212-28 Inner Gear 1
4 97212-04 Gear Carrier-Intermediate 1 29 97212-29 Gasket 9500 3
5 97212-05 Washer-1.2mm thickness 2 30 97212-30 Gear Box End Cover 1
6 97212-06 Gear Carrier-Output 1 31 97212-31 Bolt 10
7 97212-07 Outer Spline 1 32 97212-32 Brand 1
8 97212-08 Spline Positioning Ring 1 33 97212-33 Shaft Sleeve 1
9 97212-09 Drum 1 34 97212-34 Clutch Spring 1
10 97212-10 Motor Long Bolt 1 35 97212-35 Washer 1
11 97212-11 Brake Assy 1 36 97212-36 Washer 1
12 97212-12 Coupling Joint 1 37 97212-37 Clutch Steel Ball 1
13 97212-13 Rotor 1 38 97212-38 Connection of Clutch Handle 1
14 97212-14 Washer 2 39 97212-39 Bolt 1
15 97212-15 Long Bolt 2 40 97212-40 Wire Rope 1
16 97212-16 Motor End Cover 1 41 97212-41 Mount Nut 4
17 97212-17 Carbon Assy 1 42 97212-42 Lock Washer 4
18 97212-18 Stator 1 43 97212-43 Mounting Bolt 4
19 97212-19 Link Srew 4 44 97212-44 Clevis Hook 1
20 97212-20 Motor Base 1 45 97212-45 Roller Fairlead 1
21 97212-21 Nylon Bearing 2 46 97212-46 Fairlead Mount Nut 1
22 97212-22 Tie Bar 2 47 97212-47 Fairlead Mount Bolt 2
23 97212-23 Bolt 9 48 97212-48 Control Box Assy 2
24 97212-24 Lock Washer 19 49 97212-49 Handle Remote Control 1
25 97212-25 Gear Box Base 1 1
