Smittybilt XRC 8 User Manual

For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Page 13 of 17
XRC
XRC XRC
XRC 12
1212
12 Specification
Specification Specification
Specification
Rated Line Pull: 12000Lbs (5440kgs) single-line
Motor: 6.6hp/12V, Series Wound
Control: Remote Switch, 12’ (3.7m) lead
Gear Train: 3-Stage Planetary
Gear Ratio: 265:1
Clutch: Rotating Ring Gear
Brake: Automatic In-The-Drum
Drum Size: (Diameter x Length) 2.5” x 8.82” (63.5mm x 224mm)
Wire Rope: (Diameter x Length) 23/64” x 94’ (9.2mm x 28.5m)
Fairlead: 4-Way Roller
Remote Control: Included
Recommended Battery: 650CCA Minimum for Winching
Battery Leads: 25mm
2
, 72” (1.8m)
Finish: Black
Weight: 99.0lbs (45.0Kgs)
Mounting Bolt Pattern: 10.0” x 4.50”
Line speed and amp draw (first layer)
Lbs 2000 4000 6000 8000 10000 12000
Line Pull
Kgs
NO LOAD
907 1814 2722 3629 4532 5440
Fpm 23.5 12.8 10.5 9.4 7.4 6.3 5
Line Speed
Mpm 7.2 3.9 3.2 2.9 2.3 1.9 1.5
Motor Current Amps 65 120 165 215 270 320 370
Line pull and cable capacity
Layer of cable 1 2 3 4
Lbs 120000 10270 9200 8500
Rated line pull per layer
Kgs 5440 4654 4169 3852
Ft 16 42 72 94
Cable capacity per layer
Mpm 5 12 21 28
