Features
• Image Sensor
o Panasonic 1/2.7”, 2.07 million effective pixels, HD CMOS sensor
o Olympus high quality telephoto lens supporting 30X optical zoom and optional 8X digital zoom
o Full HD 1920x1080p resolution up to 60 frames per second
o 2D & 3D noise reduction with our latest “low noise CMOS sensor”
o 0.05 Lux @ F1.8 AGC On
o Wide angle 60.7° horizontal field of view
o Dynamic Range Control (DRC) for higher image quality and detail across simultaneously well lit and shadowed
scenes.
o Image Freeze to temporarily pause the video while calling presets (so viewers won’t see camera movement)
o High SNR (signal to noise ratio) of the CMOS sensor (≥55dB), combined with 2D & 3D noise reduction algorithms,
effectively reduces noise, even under low illumination conditions.
• Video Outputs
o Simultaneous IP network streaming, 3G-SDI, and HDMI video outputs.
o 3G-SDI High Definition video output up to 60 frames per second
o HDMI 1.3 High efinition video output up to 60 frames per second
o RTSP, RTMP, & RTMPS streaming using H.264, H.265, & MJPEG
o Line level audio embedding over IP network stream & HDMI. Uses AAC audio encoding for better sound quality
and lower bandwidth usage.
o Support for ultra-high FPS mode 1280x720p @ 120 frames per second over IP network stream.
o Supports non-simultaneous CVBS (composite video) output via 3.5mm connector (480i or 576i)
• Control and Settings
o VISCA over IP
o IR Remote Control
o Web-based IP remote control interface
o RS232 & RS485 VISCA, Pelco-D, & Pelco-P control
• Installation
o Standard 1/4-20 female thread for camera mounting
o Power over Ethernet – Supports 802.3af
o 12VDC 2A Power Supply provided for non-PoE infrastructure
*Please note: The camera is unable to perform 1080@60 over IP stream & SDI/HDMI simultaneously.
