1 x RJ45 IP Network streaming 10/100/1000 Ethernet port
SD Output
1 x CVBS: RCA jack, 1Vp-p, 75Ω
Network Interface
1 x RJ45: 10/100/1000M Adaptive Ethernet ports (Support POE)
Audio Input
1-ch 3.5mm audio interface, Line In (IP Network stream only) (Unbalanced stereo)
USB
1 x USB2.0: type A jack
Communication Interface
1 x RS-232 IN: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA/Pelco-D/Pelco-P
1 x RS-232 OUT: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA network use only
1 x RS-485: 2pin Phoenix port, Max Distance: 1200m, Protocol: VISCA/Pelco-D/Pelco-P
Power Jack
JEITA type (DC IN 12V)
IP Codec Features
Video Compression
H.264 / H.265 / MJPEG
Video Stream
Two (2) IP video output streams available (Main Stream, Sub Stream)
First Stream Resolutions
1920x1080, 1280x720, 1024x576, 960x540, 640x480, 640x360
Second Stream Resolutions
1280x720, 1024x576, 720x480, 720x408, 640x360, 480x270, 320x240, 320x180
Video Bit Rate
32Kbps ~ 102400Kbps
Bit Rate Type
Variable Rate, Fixed Rate
Frame Rate
50Hz: 1 FPS ~ 50 FPS, 60Hz: 1 FPS ~ 60 FPS
Audio Compression
AAC
Audio Bit Rate
96Kbps, 128Kbps, 256Kbps
Supported Protocols
TCP/IP, HTTP, RTSP, RTMP, DHCP, Multicast, etc.
Generic Specification
Input Voltage
DC 12V / PoE (802.3af) (optional)
Current Consumption
1.0A (Max)
Operating Temperature
-10°C ~ 40°C (14°F ~ 104°F)
Storage Temperature
-40°C ~ 60°C (-40°F ~ 140°F)
Operating Humidity
10% - 80%
Power Consumption
12W (Max)
MTBF
>30000h
Size in. (W x D x H)
5.6” W x 6.7” D x 6.5” H (7.8” H w/ max tilt)
Size mm. (W x D x H)
142mm W x 169mm D x 164mm H (168mm H w/ max tilt)
Camera Weight
3.01 lbs [1.35 kg]
Box Weight
5.4 lbs [2.45 kg]
