surfaceagainstthefloor.

ASSEMBLELEGS

The legs are assembled to the table by inserting the legs into the square wooden
receptacles.Thereare4suchsquarereceptaclesinthebottomofthetable,oneforeachleg.

Insert the legs intothe receptacles but do not bolt them on yet.Notethat thereare2
threadedholes on one side of each leg.These holes are for attaching the shelves, so the
legs should be inserted into the receptacles with these holes facing the other leg.The
shelvesneedtobescrewedontothelegsbeforethelegsarescrewedtothetable.

Donotskip
attachingtheshelves,evenifyoudon'tplantousetheshelvesforstorage.The
shelvesareanintegralpartofthestructureofthelegs,andareneededtoensurestabilityof
thetable.

Thesmallshelfisinsertedbetweentherearlegs,whicharelocatedatthenarrow
endof
thetable.Theshelfsurfaceshouldfacetheoutsideofthetable.Findtheshelfscrewsinone
oftheplasticbags.Inserttheshelfscrewthroughtheholeonsideofshelfintothethreaded
holeintheleg.Handtightensscrewandrepeatwithothershelf
screws.

The large shelf is installed in the same way, hand tightened between the front legs,
locatedatthewideendofthetable.Theshelfsurfaceshouldfacetheoutsideofthetable.

After both the shelves are attached to the legs, you can screw the legs to the
table
receptacle by inserting the leg bolt, with washer, through the receptacle hole into the
threadedholeintheleg.Handtightenseachlegscrewstothelegs.

Onceall leg screwsare on, use the Allenwrench totightenthe leg screwsand theshelf
screws.

Next,installthe
leglevelersonthebottomoftheleg.Theleglevelerboltshouldbehand
tightened so the round base engages the threaded bolt when rotated. Insert the threaded
boltintothe threaded holeinthe middle ofthe leg bottom,andturnit clockwiseuntilit is
nearlyall
thewaythreadedintothehole.Thenbackoffabout2turns.Repeatforthethree
otherleglevelers.

Now the table can be turned over, right side up. The table is a littleheavy, you’ dbetter
havetwoormorepeoplecarefullyliftonesideofthetableandset
ituponitslegs.

INSTALLINGSCOREBOARD

Removethescoreboardunitfromthesmallbox.Checkthescoreboardtomakesureno
