• DO NOT overfill fuel tank. Slowly add unleaded gasoline (A) to fuel tank (B). Use
extreme caution not to fill fuel above baffle (C). This allow appropriate space for
fuel expansion.
STARTING
PRIOR TO STARTING THE PRESSURE WASHER, MAKE SURE THAT YOU HAVE:
1. Selected a proper size nozzle for the job at hand (see "SELECTING THE RIGHT
NOZZLE")
2. Attached the Pressure W
asher to the water source and turned on the source
(see "ATTACHING THE PUMP TO WATER SUPPLY").
DO NOT run the pump without the water supply connect-
ed and turned on. Damage to the Pressure Washer resulting from failure to
follow this instruction WILL void the warranty.
3.
For your protection, wear protective safety glasses (provided).
4. Move the Pressure Washer OUTSIDE in a fully VENTILATED area.
5.
Place the Pressure Washer on a FLAT and level surface and close to the work-
ing sur
face. Keep a minimum of 5 ft. (1.5 meters) CLEARANCE on all sides of
the engine including top. Face the engine exhaust outlet AWA
Y from dwellings.
6. Make sure the Throttle lever is
set to the “FAST” position (left).
7. Slide the Fuel V
alve lever to “ON” position (right) to allow the fuel to flow to
the engine.
8. Slide the Choke Lever to “START” position (left).
9.
Turn the Engine ON/OFF switch clockwise to ON position.
10.Point nozzle to a safe direction and squeeze the Spray Gun
trigger to allow for easier
engine start.
LOW OIL SENSOR
To prevent the engine damage caused by an insufficient amount of oil in the crankcase,
engine is equipped with a low oil sensor. If the oil is below the safe amount, the sensor
will activate and will prevent engine start-up or will stop the running engine.
If Pressure Washer shuts off and the oil level is within specifications, check to see
if Pressure Washer is sitting at an angle that forces oil to shift.
Place on an even surface to correct this. If engine fails to start, the oil level may not
be sufficient to deactivate low oil level sensor. Add oil as described above.
ADDING FUEL
1. Move the Pressure Washer OUTSIDE and place on a flat and
level surface.
2. Remove the gas tank cap. Carefully add 87 Octane (or higher)
grade unleaded gasoline to the tank. DO NOT OVERFILL.
Leave room for the gasoline to expand.
3.
Replace and hand tighten gas cap and wipe off any spilled fuel.
Fuel and fuel vapor are extremely flammable and explosive.
Fire or explosion from misuse of fuel can cause severe burns
and even death.
Failure to use fuel as recommended in this manual will void the warranty
.
WHEN ADDING FUEL TO PRESSURE WASHER, OBSERVE THE FOLLOWING:
• DO NOT use unapproved gasoline such as E85 (85% ethanol/15% gasoline).
• DO NOT mix oil with gasoline.
• DO NOT modify engine to run on alternate fuels.
•
Turn Pressure Washer OFF and let it cool for at least two minutes before
removing fuel cap. Loosen fuel cap slowly to release pressure.
•
Keep fuel away from sparks, open flames, pilot lights, heat and other ignition
sources.
• DO NOT light a cigarette or smoke near open fuel tank or container.
•
Clean area around fuel fill cap and slowly remove cap to allow any pressure to
escape.
• Install fuel cap and allow any spilled fuel to evaporate before starting engine.
2019
CAP
FILL LINE
