Snap-On POLARTEK PLUS EEAC331 Service Manual

• 77 •
#
DESCRIPTION
Supplier
Part
Number
Snap-on
Part
Number
1
Transparent LED cover
PLA2576-03
EEAC331-12
2
LED light motherboard
SCH6600-15
3
Upper plastic carter
PLA2573-01
EEAC330-43
4
7" touch motherboard
GRSCH1452
EEAC331-17
5
Control panel fixing plate
CRP5013
6
Control panel (7" display)
CRP5003
7
Polartek PLUS panel sticker
ADE6653
EEAC331-5
8
Printer
GRSTM0007C
EEAC331-19
9
LP 100mm Gauge
MAN3151
EEAC331-10
10
HP 100mm Gauge
MAN3150
EEAC331-9
11
7" display frame
PLA2574-01
EEAC331-11
12
Right plastic cover
PLA2551-02
EEAC330-36
13
Oil door cap
PLA2570-01
EEAC330-41
14
New oil glazed sticker
ADE6556
EEAC330-2
15
UV glazed sticker
ADE6558
EEAC331-2
16
Used oil glazed sticker
ADE6559
EEAC330-3
17
Oil door
PLA2559-01
EEAC330-39
18
Filter door
PLA2560-01
EEAC330-40
19
New oil container plug – blue
RAC8083
EEAC330-58
20
UV container plug - yellow button
RAC8082
EEAC331-16
21
UV container - yellow cap
GRCNT16
EEAC331-6
22
Used oil container plug - red
RAC8080
EEAC330-57
23
Used oil container - red cap
GRCNT025
EEAC330-27
24
Used oil container support
CRP4164-V
25
Scale spacer 4mm
CRP1240
EEAC330-12
26
Scale spacer 4mm
CRP1240
EEAC330-12
27
Used oil scale - 15kg
CEL9512-E
EEAC330-10
28
Oil support bracket
CRP5036
29
Scale spacer 4mm
CRP1240
EEAC330-12
30
New oil/UV scale - 15kg
CEL9512-E
EEAC330-10
31
Scale spacer 4mm
CRP1240
EEAC330-12
32
New oil/UV containers support
CRP4076
33
New oil container - blue cap
GRCNT18
EEAC331-7
34
Power adapter protective plate
CRP4152
35
Power adapter
SCH1290
EEAC330-62
36
3/8SAE Check valve
VLV2001
EEAC330-83
37
1/8gas filter fitting
RAC5203
38
Filter manifold
DIS1348
39
Nipple 1/8gas-3/8SAE
RAC5186
40
Dryer filter
FLT5511
EEAC330-23
41
Manifold
DIS7200
42
Front plastic cover
PLA2572-01
EEAC330-42
43
Condenser with fan
GRCDN06-E
EEAC330-25
44
Double pipe union
RAC5998
EEAC330-54
45
1/4SAE Check valve
VLV2000
EEAC330-82
46
Front caster with brake
RUO7075
EEAC330-59
47
Front caster spacer
CRP5024
48
Foot bracket
CRP4198
49
Rear wheel spacer
RAC6020
#
DESCRIPTION
Supplier
Part
Number
Snap-on
Part
Number
50
300mm rear wheel
RUO7141
EEAC330-60
51
Rear wheel retainer
RUO7401
EEAC330-61
52
Rear wheel cap
TAP7140
EEAC330-67
53
Left plastic cover
PLA2550-02
EEAC330-35
54
Plastic pocket
PLA2556-01
EEAC330-38
55
Side connection plate
CRP5019
56
Side connection sticker
ADE6641
EEAC331-4
57
Aluminum HP quick fitting
RAC3006
EEAC331-15
58
Protection HP hose outlet
TAP8004
EEAC330-68
59
USB port
ELT5032
EEAC330-21
60
Protection LP hose outlet
TAP8004
EEAC330-68
61
Aluminum LP quick fitting
RAC3005
EEAC331-14
62
Antivabrion rubber
RAC0502
EEAC330-49
63
Vacuum pump
PMP3965
EEAC331-13
64
Oil drain extension
RAC8074
65
Oil drain cap
RAC8065
66
Fitting M24 - 1/8gas
RAC8056
67
10mm elbow ogive fitting
RAC9005
68
6mm elbow ogive fitting
RAC9004
69
Hose fitting 16mm
RAC8057
70
Oil pump filling hose
TUB0021
71
Hose fitting 16mm
RAC8061
72
Mount adapter fitting
RAC5602
73
Oil pump filling bracket
CRP3928
74
Oil pump filling cap
RAC8060
75
Rear plastic cover
PLA2553-02
EEAC330-37
76
Cord wrap
CRP5021
EEAC330-14
77
Compressor
GRCMP06-E
EEAC330-24
78
cable guide for power cable
ELT3230
EEAC330-18
79
Main switch (circuit breaker)
ELT3231
EEAC330-19
80
Tank fixing bolt
M6x35BOLT
81
M3 nut for plate magnet
M3NUT
82
Tank plate magnet
RAC3004
83
Reference weight ball
RAC6023
EEAC330-56
84
Scale spacer 4mm
CRP1240
85
Tank scale - 35kg
CEL9504-E
86
Scale spacer 4mm
CRP1240
EEAC330-12
87
Scale spacer 10mm
CRP3939
88
M6 nut for compression spring
M6NUT
89
Washer for compression spring
M6WASHER
90
Compression spring
RAC0522
91
Tank plate
CRP5002
92
Tank fixing bolt
M6x35BOLT
93
Tank heater
ELT3615-E
EEAC330-20
94
Tank plate2
CRP5001
95
Tank temperature probe
SNS0013
EEAC330-66
96
Refrigerant storage tank
CNT4030
EEAC330-11
97
1/4gas - 1/8gas fitting
RAC9007
98
1/8gas tap
RAC5904
EEAC330-55
99
Nipple 1/8gas-1/4SAE
RAC5810
