Snap-On POLARTEK PLUS EEAC331 Service Manual
4
of 1
of 1 rating
84 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
•
9
•
FIG
.
5
TA
N
K
RE
L
EAS
E
TAN
K
SCA
LE
RE
L
EAS
E
TAN
K
T
OO
L
S
:
S
c
re
w
drive
r
+
B
ox
spa
nn
e
r
n°10
4
2
1
5
3
6
8
10
Table of Contents
Table of Contents
3
Preparation for Removal and Disassembly
5
Checking the Connections
5
Operating Cycle
6
Recovery-Recycling Phase
6
Vacuum Phase
6
Charge Phase
6
General Operation
7
Principles of Operation
7
Product View
7
The Machine
8
Plastic Cover
8
Display Icons
9
Control Panel
9
Light Signals
9
Basic Components
10
Alarms
11
Setup
12
Language
12
Counters
12
Measure Units/Plate Number
12
Quick Setup
13
Setup Header Print
13
Set Date/Time
13
Vacuum Settings
13
Maintenance
14
A/C Pressures Check
14
Air Purge Manual
16
Calibration
16
Tank Cell
17
Oil Cell
19
Used Oil Cell
19
Tank Pressure
20
A/C Pressure
21
Temperature
22
Tank Temperature
22
Ambient Temperature
22
Restore Calibration
22
Change Dryer Filter
23
Database
25
Empty Hoses
25
Maintenance Report
26
Tank Cell Check
26
Tank Filling
27
Filling the PAG Oil Container
30
Filling the OIL2/DYE Container
31
Emptying the Used Oil Container
32
Replacing the Printer Paper
33
USB Update
34
Error Messages
37
Troubleshooting
38
Component Replacement
41
Refrigerant Tank Replacement
41
Old Tank Removal
41
New Tank Installation
42
Accuracy Verification
44
Motherboard Replacement
45
Replace Defective SD Card
47
Tank Plate Assembly
48
Load Cell and Spaces
48
Amortized Tank Plate
48
Component Testing
49
Compressor Testing
49
Vacuum Pump Testing
50
Solenoid Valve Testing
52
Leak Testing
53
Suggested Spare Parts
54
Wiring
57
Hydraulic Diagram
64
Piping List
65
Items List
65
Valves List
65
Recovery Recycling
66
Vacuum Diagram
68
New Oil Injection Diagram
68
UV Injection Diagram
69
Gas Filling Diagram
69
Emptying Hoses Diagram
70
Wiring Diagram
73
Motherboard Diagram
74
Motherboard Parts List
75
Exploded View
76
Manifold View
78
Check Valve View
80
Solenoid Valve View
80
