MANIFOLD [DIS7200]
PIPING
REF.
DESCRIPTION
Code
T1
High pressure fitting-EV1
TUB1176
T2
Low pressure fitting-EV2
TUB1177
T4
Evaporator-Filter
TUBX085
T5
Manifold heater-Condenser
TUBX086
T9
Compressor-Oil separator
TUBX088
T10
CK1-Compressor
TUBX089
T11
Pump-EV5
TUB1258
Tso
Oil discharge bypass
TUB1258
Csp
Air purge bypass
TUB1226
Tb
Condenser-Refrigerant bottle (LP side)
TUB1174
Tr
Refrigerant bottle (HP side)-Manifold
TUB1175
Tpv
EV4-Vacuum pump
TUB1259
Tsv
Vacuum pump discharge
TUB1250
Tou
Manifold-used oil container
TUB1250
Ttr
Manifold-tracer container
TUB1250
Tpag
Manifold-new PAG oil container
TUB1250
Coc
EV6-Compressor
TUB1224
Tbm
Tank 3rd connection - EV9
TUB1224
Tlp
Manifold-LP manometer
TUB1224
Thp
Manifold-HP manometer
TUB1224
ELECTRONIC VALVES
REF.
DESCRIPTION
Code
1
EV1 High pressure electronic valve
VLV1450-N + ELT1045-C
2
EV2 low pressure electronic valve
VLV1450-N + ELT1045-C
3
EV3 outlet evaporator electronic valve
VLV1450-N + ELT1045-C
4
EV4 Inlet vacuum electronic valve
VLV1450-N + ELT1045-C
5
EV5 Outlet vacuum electronic valve
VLV7000 + ELT1165
6
EV6 Oil compressor refill electronic valve
VLV1160-N + ELT1165
7
EV7 Oil discharge electronic valve
VLV1160-N + ELT1165
8
EV8 Refilling electronic valve
VLV1160-N + ELT1165
9
EV9 Evaporator overpressure electronic
valve
VLV1160-N + ELT1165
10
EV10 Air purge electronic valve
VLV1160-N + ELT1165
12
EV12 Refilling new PAG oil electronic valve
VLV1160-N + ELT1165
14
EV14 Dye tracer electronic valve
VLV1160-N + ELT1165
ITEMS
REF.
DESCRIPTION
Code
7
Safety valve (12bar)
VLV2102
8
A/C Pressure Transducer
TRS9000-SC
14
Safety Pressur switch (20 bar)
PRS4325-D
32
Bottle pressure transducer
TRS9000-SC
34
Vacuum pump safety valve (1 bar)
VLV2204
35
Air purge filter
RAC5885
