Snap-On SVTS272 User Manual

7
1
2
3
4
7
5
6
9
8
10
11
12
13
* SVTS272-1 Cooling system Tester Pump
(#1-5) in cardboard box
* SVT262-23 Plastic Carrying Case (not shown)
1 SVTS263-2 Heavy Duty Pressure Gauge with Rubber Boot
2 SVTS27232 Pump Assembly with knob (gauge not included)
3 SVT261-3 Knob only
4 SVTS27233 Tester Head with Hose Assembly
Note: Hose may be field repaired - use 3/16” ID fuel hose
5 SVT262-19 Tester Seal
6 SVT262-22 Spacer Washer (1/4” thick rubber washer for 1” deep filler necks)
7 SVT262-28A 32mm x 16mm deep Radiator Adaptor with Seal, Silver
8 TA38C 32mm x 9mm deep Radiator Adaptor with Seal, Gold
9 SVT262-30 Rubber Seal for 32mm Radiator Adaptor
10 TAB10036 Radiator Adaptor with Seal
11 TA10036G Rubber Seal for #TAB10036
12 TA10052R Rubber O-ring for #TAB10036/TAB10052
13 TAB10052 Radiator Adaptor with Seal
