12 SnapperPro.com
23
Lubricate the Front Casters
Interval:Annually
1. Remove the 1/4-28 bolt (A, Figure24) screwed into the
caster and install a 1/4-28 grease fitting.
24
2. Grease the front caster.
3. Remove the 1/4-28 grease fitting and reinstall the 1/4-28
bolt.
4. Repeat the process for the other side of the machine.
Checking / Adding Fuel
WARNING
Gasoline is highly flammable and must be handled with
care. Allow engine to cool for at least 3 minutes before
refueling. Do not allow open flame, smoking or matches in
the area. Avoid over-filling and wipe up any spills.
To add fuel:
1. Remove the fuel cap (A, Figure25).
25
2. Fill the fuel tank to the bottom of the filler neck. This will
allow for fuel expansion.
Note: Do not overfill. Refer to your engine owner's
manual for specific fuel recommendations.
3. Install and hand tighten the fuel cap.
4. If your unit is equipped with two fuel tanks, repeat this
process to fill the other fuel tank.
NOTICE
Refer to your engine owner's manual for specific fuel
recommendations.
Starting the Engine - Carbureted Models
1. While standing on the operator's platform, engage
the parking brake, make sure that the PTO switch is
disengaged, and that the ground speed control levers are
in the NEUTRAL position.
2. A warm engine may not require choking. Set the
engine throttle control to FAST throttle position. Then fully
close the choke by pulling the knob OUT fully.
3. Insert the key into the ignition switch and turn it to
START.
4. After the engine starts, gradually open the choke (push
knob down fully). Reduce to half throttle speed and allow
engine to warm. Warm up the engine by running it for
atleast a minute before engaging the PTO switch or
driving the rider.
5. After warming the engine always operate the unit at FULL
throttle when mowing.
In the event of an emergency the engine can be stopped
by simply turning the ignition switch to STOP.
