14
www.SnapperPro.com
Operation
Figure 5. Seat Adjustment
A. Seat Adjustment Lever
Seat Adjustment
See Figure 5. The seat can be adjusted forward and
backward. Move the lever towards the left, position the
seat as desired, and release the lever to lock the seat into
position.
Figure 4. Checking Tire Pressure
Check Tire Pressures
Tire pressure should be checked periodically, and
maintained at the levels shown in the chart. Note that these
pressures may differ slightly from the “Max Inflation”
stamped on the side-wall of the tires. The pressures shown
provide proper traction, improve cut quality, and extend tire
life.
A
Tire
Pressure
Front (S/N: 2013129510 & Below) 40 psi (2,76 bar)
Front (S/N: 2013129511 & Above) 25 psi (1,72 bar)
Rear
15 psi (1,03 bar)
