www.snapper.com10
Operation
Stopping - Engine,
Wheel Drive, Blade
Engine
1. Stop the engine by turning the key (A, Figure 13) to the
“OFF” position.
Wheel Drive
1. Stop motion of the Rear Engine Rider by pushing the
clutch/brake pedal (A, Figure 14) all the way down to
apply the brake.
Mower Blade
1. Stop the mower blade by releasing the blade pedals (A,
Figure 15) or moving the blade lever (B) rearward to the
“OFF” position.
Operation (Continued)
WARNING
DO NOT leave the machine with the engine running. STOP
Blade. STOP engine. Shift to neutral and engage park brake.
Remove key.
!
!
WARNING
Once blade is disengaged, it should come to a complete
stop in 3 seconds or less. If the blade continues to rotate
after 3 seconds, the blade brake must be adjusted. Refer to
Section “BLADE BRAKE ADJUSTMENT” for adjustment pro-
cedures or return machine to an authorized SNAPPER deal-
er for adjustment. DO NOT CONTINUE to operate machine
until blade brake is adjusted and functioning properly.
!
!
Figure 13: Turning key to ‘Off’
A
Figure 15: Stopping the mower blade
B
A
Figure 14: Engaging the clutch/brake pedal
A
