Snapper 3011523BV User Manual

5
Features and Controls
IMPORTANT
The figures and illustrations in this manual are provided
for reference only and may differ from your specific
model. Contact your Snapper dealer if you have questions.
Features and Controls
A. Steering Wheel
B. Engine Speed Control (hidden from view)
C. Ignition Switch
D. Clutch/Brake Pedal
E. Park Brake Latch
F. Blade Pedal
G. Blade Lever
H. Discharge Deflector
I. Override Control
J. Transmission Shift Lever
K. Fuel Tank
F
B
H
I
K
D
G
E
J
A
C
Features and Controls

Snapper 3011523BV Specifications

General

Brand	Snapper
Model	3011523BV
Category	Lawn Mower
Language	English
