27
Checking / Adding Fuel
To add fuel:
1. Remove the fuel cap.
2. Fill the tank to about 1-1/2” (3,81 cm) of the bottom of
the filler neck. This will allow for fuel expansion.
NOTE: Do not overfill. Refer to your engine manual
for specific fuel recommendations.
3. Install and hand tighten the fuel cap.
Fuel Filter
The fuel filter is located in the fuel line between fuel tank and
carburetor, near the fuel pump. If filter is dirty or clogged,
replace as follows:
1. Disconnect the negative battery cable.
2. Place a container below the filter to catch spilled fuel.
3. Using pliers, open and slide hose clamps from fuel filter.
4. Remove hoses from filter.
5. Install new filter in proper flow direction in fuel line.
6. Secure with hose clamps.
7. Reconnect the negative battery cable when finished.
Change Oil & Filter
1. Warm engine by running for a few minutes. (Refer to
the engine operator’s manual for oil & filter replacement
instructions.)
2. Remove the oil drain hose (A, Figure 20) from the cable
clamp (C) that is located on the engine deck on the
right-hand side of the frame. Place the drain hose down
through the hole (E) in the engine deck.
3. Place a small pan under the oil drain hose to catch the
oil. Using the appropriate tools, remove the cap (B)
from the oil drain hose (A) and drain the engine oil into
the pan.
4. After draining, replace the cap and wipe up any spilled
oil. Reinstall the oil drain hose into the cable clamp to
retain the hose during normal operation.
5. Place an absorbent shop cloth under the engine oil filter.
Remove the engine oil filter and replace with a new one.
6. Remove the shop cloth and wipe up any spilled oil.
Inspect Muffler and Spark Arrester
Inspect the muffler for cracks, corrosion, or other damage
Remove the spark arrester, if equipped, and inspect
for damage or carbon blockage. If replacement parts
are required, make sure to use only original equipment
replacement parts.
Engine Maintenance
Refer to engine owner’s manual for all engine maintenance
procedures and recommendations.
WARNING
Gasoline is highly flammable and must be
handled with care. Never fill the tank when the
engine is still hot from recent operation. Do not
allow open flame, smoking or matches in the
area. Avoid over-filling and wipe up any spills.
Do not remove fuel filter when engine is hot,
as spilled gasoline may ignite. DO NOT spread
hose clamps further than necessary. Ensure
clamps grip hoses firmly over filter after
installation.
Regular Maintenance
Figure 20. Engine Oil Drain
A. Oil Drain Hose
B. Cap
C. Cable Clamp
D. Oil Filter
E. Hole for Drain Hose
NOTICE
Do not use gasoline containing METHANOL,
gasohol containing more than 10% ethanol,
gasoline additives, premium gasoline, or white
gas because engine/fuel system damage could
result.
C
B
A
D
E
WARNING
Replacement parts must be the same and
installed in the same position as the orginal
parts or fire could result.
