SECTION 1 – FAMILIARIZATION
BRAKE
PEDAL
ACCELERATOR
PEDAL
DASHBOARD / PEDAL CLUSTER
DIFFERENTIAL
LOCK LEVER
HOURMETER/TACHOMETER/
SERVICE MINDER COMBO
SPEEDOMETER/FUEL GAUGE
COMBO
ELECTRIC WINCH
SWITCH (OPTIONAL)
STEERING WHEEL
IMPORTANT NOTE: DUE TO SPACE
LIMITATIONS, THE BRAKE AND
ACCELERATOR PEDALS ARE OFFSET
TO THE RIGHT OF THE OPERATOR’S
SEAT. OPERATOR MUST EXERCISE
EXTREME CAUTION WHEN FIRST
OPERATING THE VEHICLE, UNTIL
FAMILIAR WITH PEDAL OFFSET.
CHOKE KNOB
TRANSMISSION
SHIFT LEVER
12V ACCESSORY
PLUG
BED LIFT SWITCH
(OPTIONAL)
PARKING BRAKE
KNOB
IGNITION
SWITCH
BEVERAGE
HOLDERS
CONTROL CONSOLE
HEADLIGHT
SWITCH
HAND
GRIP
9
FUSE
PANEL
STORAGE TRAY
