Footnotes:
Manual No.
7106251SP105 21" ELECTRIC START
775 SERIES
5
Handle Group
Part No Descri
tionItem Qty
4 703486 NUT, Square, 1/4-20
5 703530 HANDLE, Lower
6 703483 BOLT, Carriage, 5/16-18 x 1, GR5
24 703463 NUT, Flange Lock, 1/4-20
25 1101453MA KNOB, Wing, 5/16-18
36 705881 PLATE, Cable Adjust
37 705882 HANDLE, Upper
38 7091081SM SCREW, 1/4-15 x 3/4
39 110122MA KNOB, 1/4-20
40 1701011SM TIE, Self Lock
41 703485 GUIDE, Rope
42 705883 CABLE, Drive
43 703561 CABLE, Control
44 705884 BAIL, Blade Control
45 705885 NUT, Wing
46 703522 BOLT, Shoulder, 1/4-20
77 705888 CABLE, Speed Adjustment
80 705891 SCREW, Shoulder, 1/4-15 x 1
81 705892 HOUSING, Lower
82 705893 ACTUATOR, Speed Adjust
83 705894 LEVER, Speed Select
84 705895 LEVER, Control, LH
85 705896 HOUSING, Upper
86 705897 LEVER, Control, RH
87 705898 SPRING
